ARTURIA AUDIOFUSE STUDIO USB ZVUČNA KARTICA

8 analog input channels (4 DiscretePRO microphone preamps)

10 optical inputs

20 outputs

Inputs: 4x XLR combo input (mic/inst./line); 4x 6.3mm balanced jack input (channels 5-8: phono/line); 2x RCA phono input; optical S/PDIF input; optical Adat input; Word clock input; 3.5mm stereo jack MIDI input

Outputs: 4x 6.3mm balanced jack output (SPEAKER A (L/R); SPEAKER B (L/R)); 2x 6.3mm stereo jack headphones output; 2x 3.5mm stereo jack headphones output; optical S/PDIF output; Word clock/ S/PDIF output; 3.5mm stereo jack MIDI output; optical ADAT output

USB: 3x USB A-type; mini USB (DAW connection)

2x 6.3mm balanced jack insert input; 2x 6.3mm 6.3mm balanced jack insert output

Channel controls: 48V phantom power; phase invert; PAD; instrument input impedance switch; gain control; listen switch

Monitoring: CUE select; MONO; DIM; MUTE; speaker select; output level control

Headphones: CUE select; MONO; headphones level control

Talkback

Direct monitoring / Computer monitoring

Power modes

Re-Amping

Playback and sampling from vinyl via the phono RIAA preamps

External effect connection via the insert point

ADAT input/output extension (max. 8 additional inputs/outputs)

High-end DiscretePRO microphone preamps

Bluetooth connectivity

Bit depth: 16bit; 24bit; 32bit floating

Sample rate: 44.1kHz; 48kHz; 96kHz; 192kHz

Power supply / USB cable
